200W Slim LED Flood Light IP65 256 x 2835 LED

The largest of the slim 5111 floods, the 5111F200-01 puts 256 2835 LEDs behind one 200W lens for wide-area coverage from a single fitting. It is specified for depots, transport yards, training grounds and large compounds running on mains power.

Rated output is 160 lm/W with a colour rendering index above 70Ra and a stated LED life span of 50,000 hours, and the model is offered from 3000K to 6000K. Spreading the LEDs across a broad die-casting aluminium housing keeps the heat load per chip low, and the 45 mm depth still counts as slim for this wattage. The fitting is sealed to IP65, and the driver takes AC 100-240V at 50Hz with a power factor of 0.95 or higher.

At 380 x 280 x 45 mm the lamp needs a properly rated bracket, and the manufacturer recommends an install height of 6-8 m: a pole, a mast or a high wall. It works for yard and perimeter lighting, pitch and ground lighting, container areas and building floodlighting. The manufacturer's stated warranty is 3 years.

Specifications

• Power: 200W
• LED chip: 2835 LED, 256 pieces
• Colour temperature: 3000K-6000K
• Efficacy: 160 lm/W
• Colour rendering index: above 70Ra
• LED life span: 50,000 hours
• Input voltage: AC 100-240V, 50Hz
• IP rating: IP65
• Power factor: 0.95 or higher
• Material: die-cast aluminium
• Lamp size: 380 x 280 x 45 mm
• Recommended install height: 6-8 m
• Warranty: manufacturer's stated warranty of 3 years
