90W Solar LED Street Light Motion Sensor 86Ah

Stepping up a size in the 0418 series, the 0418B90-03 is a 90W solar LED street light in aluminium alloy, listed for four to six metre mounting. It is the size most often chosen for access roads and larger compounds within the 0418 series.

Seventy-two 3030 LEDs at 6000K carry a rated 160 lm/W. What sets this model apart from the smaller head is the battery: a LiFePO4 3.2V 86Ah pack, twice the store, charged from a 6V 80W mono-crystalline panel in a stated 6 to 8 hours. The manufacturer gives a discharging time of 30 to 36 hours, so on a site with clear sun the lamp holds a substantial reserve against a dull day. A motion sensor works with light control to lift output only when there is movement, which is what makes those hours realistic. The head measures 1127 x 407 x 209mm.

Contractors use it on estate and access roads, industrial yards, school and clinic grounds, church compounds and staff housing schemes. Mount it with the panel clear of tree cover and facing open sky.

Specifications

• Rated power: 90W solar LED street light
• LED: 3030 LED, 72 pcs, 6000K
• Efficacy: 160 lm/W
• Solar panel: 6V 80W mono-crystalline
• Battery: LiFePO4 3.2V 86Ah
• Charging time: 6-8 hours
• Discharging time: 30-36 hours
• Control: motion sensor and light control
• Material: aluminium alloy
• Product size: 1127 x 407 x 209mm
• Install height: 4-6 metres
• Warranty: manufacturer's stated warranty of 3 years
