MODI M1 45A Cooker Control Unit with 13A Socket Outlet

Kitchens rarely have wall space to spare, and the M1-035 answers that by putting a 45A cooker switch and a 13A switched socket behind one flush plate. The cooker side isolates the appliance for cleaning or servicing; the socket side keeps a working outlet at counter height without a second chase in the wall.

The plate is moulded in high-quality PC material that is self-extinguishing and flame-retardant, a sensible property on a plate that sits close to a heat source. Internal copper parts carry the load and resist electrical corrosion, while the one-piece moulded body holds its geometry through years of switching. Wiring is internal, which shortens the time an installer spends dressing conductors into the box.

Typical uses are domestic kitchens, staff kitchens in offices, hostel and rental blocks, and any fit-out where the cooker point and a general socket need to sit together. Available in white, gold, grey and black to sit alongside the rest of the M1 range on the same job.

Specifications

• Model: M1-035 (V1-035 series)
• Type: 45A cooker switch with 13A socket
• Panel material: PC, self-extinguishing and flame-retardant
• Contacts: selected internal copper parts
• Construction: one-piece moulding
• Wiring: internal wiring terminals
• Colours: white, gold, grey, black
• Packing: 50 pieces per carton
