MODI MD-PLM50 LED Panel Light 15W 24W and 36W White

MODI's MD-PLM50 is a round LED panel sold in three outputs, 15W, 24W and 36W, which cover most domestic and small commercial ceilings from a single range. The 15W gives 1450 lumens on a 233mm body, the 24W gives 2400 lumens on 298mm and the 36W gives 3600 lumens on 378mm, so output and physical size step up together.

The housing is PC throughout, with a free open hole design and a push-pull buckle that adjusts the opening size, meaning one fitting suits a range of cut-outs and an existing ceiling hole can often be reused. Drive is by an external constant current isolation segment driver. Colour rendering is quoted at 80 or above, higher than many panels at this price, and colour temperatures of 3000K, 4000K and 6500K are listed for the series. Rated life is 25,000 hours at a working ambient of up to 45 degrees Celsius, on AC220-240V 50/60Hz with an operating range of AC175-265V.

Fit them through bedrooms, sitting rooms, kitchens, corridors, offices, clinics and shops.

Specifications

• Series: MD-PLM50
• 15W: 1450 lumens, 233 x 45mm
• 24W: 2400 lumens, 298 x 45mm
• 36W: 3600 lumens, 378 x 46mm
• Voltage: AC220-240V 50/60Hz (operating AC175-265V)
• CRI: 80 or above
• Beam angle: 120 degrees
• Colour temperature: 3000K / 4000K / 6500K
• Rated life: 25,000 hours
• Power factor: above 0.5
• Surge protection: 1.5KV
• Material: PC
