10200W Hybrid Solar Inverter 48V MPPT On and Off Grid

Top of the STM hybrid range, model STM102248 delivers 10200W from a 48V battery bank. It is the choice where the 8200W unit runs out of headroom: boreholes and irrigation, workshop tools, hotels and larger commercial premises that want solar first, grid second and batteries overnight.

PV input is tracked by a single MPPT working across 90 to 450VDC, nominally 360VDC, with a 500VDC open-circuit ceiling and a maximum PV charging current of 160A. Keeping the string between 360 and 450VDC holds full-load tracking, and peak DC to AC conversion efficiency is quoted at 98% with power factor better than 0.99. Nominal AC output is 220, 230 or 240VAC at 44.3A, and grid feed-in is accepted from 195 to 253VAC at 49-51Hz. Loads split across two outputs: a main output carrying the full 10200W and a second rated to 3400W for non-critical circuits, with main load cut-off at 44VDC.

Installers use it for hybrid, on-grid and off-grid builds on farms and commercial rooftops.

Specifications

• Model: STM102248
• Rated output power: 10200W
• Battery system voltage: 48V
• PV nominal operating voltage: 360VDC
• Maximum PV array open circuit voltage: 500VDC
• MPPT operating voltage: 90-450VDC (full load 360-450VDC)
• MPPT trackers / maximum input current: 1 / 27A
• Maximum PV charging current: 160A
• Feed-in grid range: 195-253VAC, 49-51 (+/-1) Hz
• Nominal output: 220/230/240VAC at 44.3A, 50/60Hz
• Power factor: greater than 0.99
• Maximum conversion efficiency (DC/AC): 98%
• Second load output: up to 3400W
• Main load cut-off voltage: 44VDC
